华北地区典型岩石在1万巴压力下的密度和弹性波速度的实验研究s
AN EXPERIMENTAL STUDY ON THE DENSITY AND ELASTIC WAVE VELOCITY OF TYPICAL ROCKS OF NORTH CHINA UNDER HIGH PRESSURE UP TO 10kb
-
摘要: 利用高压三轴容器,对华北地区九种典型岩石的密度和弹性波速度随压力的变化关系进行了实验研究。实验的最高压力达到10,500巴。实验中利用电阻应变片测量岩石的体积变化从而得到密度的变化。用高频脉冲法测量了弹性波速度。由得到的密度参数和波速参数计算出高压下岩石的声阻抗。根据体应变和波速随压力变化的曲线估算了岩石的体积模量,裂纹孔隙度,裂纹闭合压力,波速达到稳定变化时的压力以及波速达到稳定变化时的值与常压下的波速值的差。对这些参数在地学及爆破工程上的应用进行了简单的讨论。Abstract: An experimental study on variation of density and elastic wave velocity on nine typical rocks of North China was made by using a high presswre triaxial vessel. The maximum pressure in the experiments was 10.5kb. The volumetric strain was measured by means of resistance strain gauges and the variation of density was thus deduced. The elastic wave veloity was measured by the high frequency impulse method. Then the acoustic impedance under high pressure was calculated by parameters of density arid wave velocity. Prom the variation curves of volumetric strain and wave velocity with changes in pressure,the following quantities were calculated: the bulk modulus,the void ratio of cracks,the pressure of closing cracks,and the difference between the values of wave velocity above the pressure when it begins to change steadily and that at atmospheric pressure. The applications of these parameters to the earth sciences and explosion engineering was briefly discussed.
