Development of a low-power broadband seismometer-integrated data logger
-
摘要: 流动观测台网与固定观测台网的结合是当前地震观测技术系统发展的一个趋势. 针对流动观测时地震计与地震数据采集器互相独立、 携带不方便、 功耗高的问题， 自主研发了一款适合流动观测的集地震信号提取、 数据采集、 记录和服务为一体的数字地震仪. 该仪器具有频带宽(60 s—80 Hz)、 动态范围高(>140 dB)、 功耗低(0.6 W)、 携带方便(整机重量在15 kg左右， 包括供电系统、 GPS天线和包装箱)等特点. 详细介绍了该地震仪的外观结构、 整体硬件结构、 低功耗处理技术和所采用的灵敏度校正、 标准方位和正交校正技术. 对仪器的主要性能参数指标进行了严格的测试， 并给出了具体的测试结果. 该仪器研制完成后， 投入到了青海玉树MS7.1地震震后流动观测中. 从半年的实际使用结果来看， 该仪器能够满足流动观测的要求.Abstract: Combination of mobile and fixed network observations is one development tendency of current seismic observation system. In order to solve the problems such as mutual independence between seismometers and seismic data acquisition instruments, inconvenient portability and high power consumption in mobile observation, this study develops a new low-power broadband sensor-integrated data logger, which contains a three-component seismometer, a data acquisition unit, a recording device and services. The instrument has a wide frequency bandwidth (60 s—80 Hz), high dynamic range (>140 dB) and low-power consumption (0.6 W), and is easy to carry. Whole weight of the instrument is about 15 kg, including the power supply system, GPS antenna and crates. This paper describes its apparant structure, hardware structure, low-power processing techniques, sensitivity correction, standard orientation and the orthogonal correction technique in detail. We have rigorously tested the main performance parameters of the instrument and given the specific test results. After the development of instrument was completed, we put it into mobile observation after the 2010 Yushu MS7.1 earthquake. The test results show that this instrument can meet the requirements of mobile observation.
-
-
![]()
图 6 南北剖面台站(三角形)位置
Figure 6. Deployment of stations (denoted by triangles) for the NS observation profile
![]()
图 7 JDX台站记录到的2010年5月29日青海省玉树MS5.9地震
Figure 7. The 29 May 2010 MS5.9 earthquake in Yushu, Qinghai of China, recorded by the station JDX
表 1 灵敏度测试结果
Table 1 Test result of sensitivity
测试频率/Hz 响应灵敏度/(count·μm-1·s-1) UD EW NS 5.0 503.774 502.226 506.015
下载: 导出CSV
表 2 线性度测试结果
Table 2 Test result of linearity
频率/Hz 信号源输入/V UD EW NS 被测仪器输出/count 线性拟合结果/count 被测仪器输出/count 线性拟合结果/count 被测仪器输出/count 线性拟合结果/count 1 1321265 1318186 1046320 1044447 1015009 1013827 2 2640482 2637392 2091207 2088685 2028991 2027645 3 3957207 3956597 3134036 3132922 3041847 3041463 4 5274885 5275803 4176722 4177160 4055317 4055280 5 6591787 6595009 5218334 5221397 5067499 5069098 5.0 6 7910342 7914214 6261688 6265635 6080917 6082916 7 9228467 9233417 7306788 7309872 7094492 7096734 8 10549850 10552625 8352665 8354109 8109529 8110552 9 11872650 11871831 9399388 9298347 9124821 9124369 10 13199180 13191037 10448010 10442584 10141650 10138187 线性度 0.234％ 0.179％ 0.117％
下载: 导出CSV
表 3 4种处理方式可节省的功耗
Table 3 Saved power consumption for four processing modes
处理方式 可节省功耗/W 降低CPU主频 0.2 关闭网络电源 0.3 关闭GPS电源 0.2 LED显示关闭 0.3
下载: 导出CSV
-
陈祖斌, 滕吉文, 林君, 张林行. 2006. BSR-2宽频带地震记录仪的研制[J]. 地球物理学报, 49 (5): 1475-1481. Chen Z B, Teng J W, Lin J, Zhang L X. 2006. Design of BSR-2 broad band seismic recorder[J]. Chinese J Geophys, 49 (5): 1475-1481 (in Chinese).
郭建, 刘光鼎. 2009. 无缆存储式数字地震仪的现状及展望[J]. 地球物理学进展, 24 (5): 1540-1549. Guo J, Liu G D. 2009. Current situation and expectation of cable-less seismic acquisition system[J]. Progress in Geophys, 24 (5): 1540-1549 (in Chinese).
李江, 庄灿涛, 薛兵, 朱小毅, 陈阳, 朱杰, 彭朝勇, 叶鹏, 梁鸿森, 刘明辉, 杨桂存, 周银兴, 林湛, 李建飞. 2010. 宽频带海底地震仪的研制[J]. 地震学报, 32 (5): 610-618. Li J, Zhuang C T, Xue B, Zhu X Y, Chen Y, Zhu J, Peng C Y, Ye P, Liang H S, Liu M H, Yang G C, Zhou Y X, Lin Z, Li J F. 2010. Development of broadband ocean bottom seismogram (OBS)[J]. Acta Seismologica Sinica, 32 (5): 610-618 (in Chinese).
刘瑞丰, 高景春, 陈运泰, 吴忠良, 黄志斌, 徐志国, 孙丽. 2008. 中国数字地震台网的建设与发展[J]. 地震学报, 30 (5): 533-539. Liu R F, Gao J C, Chen Y T, Wu Z L, Huang Z B, Xu Z G, Sun L. 2008. Construction and development of digital seismograph networks in China[J]. Acta Seismologica Sinica, 30 (5): 533-539 (in Chinese).
陆其鹄, 吴天彪, 林君. 2009. 地球物理仪器学科发展研究报告[J]. 地球物理学进展, 24 (2): 750-758. Lu Q H, Wu T B, Lin J. 2009. A research report on development of instrument science for geophysics[J]. Progress in Geophys, 24 (2): 750-758 (in Chinese).
王超, 宋克柱, 唐进. 2007. 高性能水平地震数据采集系统设计与实现[J]. 吉林大学学报: 工学版, 37 (1): 168-172. Wang C, Song K Z, Tang J. 2007. High performance data acquisition system for marine seismic survey[J]. Journal of Jilin University: Engineering and Technology Edition, 37 (1): 168-172 (in Chinese).
王洪体, 庄灿涛, 薛兵, 李江, 陈阳, 朱小毅, 娄文宇, 刘明辉. 2006. 数字地震观测网络通讯与记录系统[J]. 地震学报, 28 (5): 540-545. Wang H T, Zhuang C T, Xue B, Li J, Chen Y, Zhu X Y, Lou W Y, Liu M H. 2006. A network communication and recording system for digital seismic observation[J]. Acta Seismologica Sinica, 28 (5): 540-545 (in Chinese).
游庆瑜, 刘福田, 冉崇荣. 2003. MC1微功耗宽频带数字地震仪[J]. 地球物理学报, 46 (3): 347-351. You Q Y, Liu F T, Rang C R. 2003. Micro-power broad digital seismograph[J]. Chinese J Geophys, 46 (3): 347-351 (in Chinese).
郑秀芬, 欧阳飚, 张东宁, 姚志祥, 梁建宏, 郑洁. 2009. "国家数字测震台网数据备份中心"技术系统建设及其对汶川大地震研究的数据支撑[J]. 地球物理学报, 52 (5): 1412-1417. Zheng X F, Ouyang B, Zhang D N, Yao Z X, Liang J H, Zheng J. 2009. Technical system construction of Data Backup Centre for China Seismograph Network and the data support to researches on the Wenchuan earthquake[J]. Chinese J Geophys, 52 (5): 1412-1417 (in Chinese).
专业设备性能指标测试检测方法标准研究课题组. 2011. 地震计测试方法及技术要求[R]. 北京: 中国地震局地震预测研究所: 3-38. Research Group of Standards for Professional Equipment Performance Testing Methods. 2011. Seismometer Test Methods and Technical Requirements[R]. Beijing: Institute of Earthquake Science, China Earthquake Administration: 3-38 (in Chinese).
Charles R H, John R E, Fred F, Robert L N, Erhard W. 2010. Guidelines for Standardized Testing of Broadband Seismometers and Accelerometers[R]. Reston, Virginia: US Geological Survey: 1-61.
Ringler A T, Hutt C R. 2010. Self-noise models of seismic instruments[J]. Seism Res Lett, 81 (6): 972-983.
Yu X L, Sun Y R, Liu J Y, Miao J F. 2010. Design and realization of synchronization circuit for GPS software receiver based on FPGA[J]. Journal of Systems Engineering and Electronics, 21 (1): 20-26.
