Characteristic analysis of the lithospheric magnetic anomaly before the Madoi MS7.4 earthquake on 22th May 2021
-
摘要: 本文利用2019年和2020年两期的全国流动地磁矢量数据，针对玛多MS7.4地震震中附近的岩石圈磁场空间分布，分析研究了岩石圈磁场各个分量的震前变化特征。结果表明，玛多MS7.4地震发生前，震中附近的岩石圈磁场分量均发生了不同程度的变化：震中位于各分量的弱变化区域和零变线附近；震中位于各分量的高梯度带和低梯度带之间。本文证实了地震发生前会引起岩石圈磁场变化这一现象，并总结了震前地磁分量的变化特征，为今后强地震（尤其是M≥7.0地震）的震磁关系研究提供了一个震例参考。Abstract: This paper analyzes and studies the magnetic anomaly characteristics of each component of the lithospheric magnetic field in the view of pre-earthquake changes of the lithospheric magnetic field near the epicenter of the Madoi MS7.4 earthquake using geomagnetic field vector data of the mainland of China in 2020 and 2019. The results show that before the Madoi MS7.4 earthquake, the lithospheric magnetic field components near the epicenter all changed to varying degrees. The Madoi MS7.4 earthquake epicenter is located at the weakly magnetic anomaly region, and near the zero-variation line of all the components. The Madoi MS7.4 earthquake epicenter is located between the high gradient belt and the low gradient belt of all the components. This paper confirms that the lithospheric magnetic anomaly will be changed before the earthquake, and summarizes characteristics of geomagnetic components magnetic anomaly, and provides a case for the future study of the seismo-magnetism, especially the earthquakes that magnitude larger than 7.0.
-
-
![]()
图 3 岩石圈磁场垂直分量（a）、水平分量（b）、北向分量（c）和东向分量（d）变化值分布图
Figure 3. Distribution of variation value of the vertical （a），horizontal （b），north （c） and east （d） component of the lithospheric magnetic field
![]()
图 1 玛多MS7.4地震震中周围地区地质构造简图
Figure 1. Schematic tectonic map around epicenter of Madoi MS7.4 earthquake
![]()
图 2 岩石圈磁场总强度（a）、磁偏角（b）和磁倾角（c）变化值分布图
Figure 2. Distribution of variation value of the total intensity （a），declination （b） and inclination （c）component of the lithospheric magnetic field
表 1 日变通化三分量均方差
Table 1 The mean square error of three-component in diurnal variation reduction
时间 通化台 Fσ /nT Dσ /′ Iσ /′ 2019 CDP （成都台） 0.56 0.14 0.07 DUL （都兰台） 0.55 0.17 0.07 JYG （嘉峪关台） 0.72 0.15 0.03 LZH （兰州台） 0.44 0.15 0.06 TSY （天水台） 0.13 0.13 0.09 2020 CDP （成都台） 0.33 0.09 0.04 GLM （格尔木台） 0.48 0.10 0.04 JYG （嘉峪关台） 0.50 0.13 0.04 LZH （兰州台） 0.28 0.08 0.04 TSY （天水台） 0.33 0.13 0.02
下载: 导出CSV
表 2 数据处理过程中的物理量及其含义
Table 2 The implication of physical quantities in data processing
物理量 含义 ${F}_{P}^{ {\rm{0} } } $ 测点P通过日变通化得到通化零时的结果 ${F}_{P}^{ {{t} } } $ 测点P在时间t时的地磁测量值 ${F}_{S}^{ {{t} } } $ 通化参考台S在时间t时的观测分钟值数据 ${F}_{S}^{ {{0} } } $ 通化参考台S在所处时区地方时00:00—03:00的连续观测分钟值数据平均值 ${F}_{P}^{{\rm{sv}}} $ 测点P经过长期变化改正到标准地磁年代的结果 $ { \Delta }_{P}^{{\rm{sv}}} $ 测点P处地磁场长期变化改正参考数值 ${F}_{P}^{ {{a} } } $ 测点P经地磁正常场剥离后所获得的岩石圈磁场数值 ${F}_{P}^{ {{{\rm{n}}} } } $ 测点P处的地磁正常场参考数值
下载: 导出CSV
表 3 岩石圈磁场分量变化极值的位置和强度
Table 3 Location and intensity of extreme values of lithospheric magnetic anomalies
地磁场分量 ΔF ΔD ΔI ΔZ ΔH ΔX ΔY 东经/° 103.00 102.05 94.89 102.91 94.92 102.91 94.89 102.04 102.92 94.94 102.91 94.92 94.89 102.91 北纬/° 34.85 36.00 32.00 35.36 32.00 35.36 32.00 36.02 35.36 32.00 35.36 32.00 32.00 35.36 极值 9.51 nT −9.81 nT 3.58′ −1.25′ 1.02′ −1.35′ 10.24 nT −13.15 nT 18.20 nT −11.25 nT 17.63 nT −11.10 nT 34.46 nT −11.94 nT
下载: 导出CSV
-
陈斌,顾左文,高金田,袁洁浩,狄传芝. 2011a. 2005.0年代中国地区地磁场及其长期变化球冠谐和分析[J]. 地球物理学报,54(3):771–779. Chen B,Gu Z W,Gao J T,Yuan J H,Di C Z. 2011a. Analyses of geomagnetic field and its secular variation over China for 2005.0 epoch using Spherical Cap Harmonic method[J]. Chinese Journal of Geophysics,54(3):771–779 (in Chinese).
陈斌,顾左文,狄传芝,高金田,袁洁浩. 2011b. 2009—2010年大华北岩石圈磁异常分布及其变化特征[J]. 云南大学学报(自然科学版),33(5):548–553. Chen B,Gu Z W,Di C Z,Gao J T,Yuan J H. 2011b. Distributions of the lithospheric magnetic anomalies and its variations in North China from 2009 to 2010[J]. Journal of Yunnan University,33(5):548–553 (in Chinese).
陈斌,袁洁浩,王粲,徐如刚,王振东. 2017. 流动地磁监测数据处理流程[J]. 地震研究,40(3):335–339. doi: 10.3969/j.issn.1000-0666.2017.03.002 Chen B,Yuan J H,Wang C,Xu R G,Wang Z D. 2017. Data processing flowchart of Chinese mobile geomagnet monitoring array[J]. Journal of Seismological Research,40(3):335–339 (in Chinese).
邓起东,张培震,冉勇康,杨晓平,闵伟,陈立春. 2003. 中国活动构造与地震活动[J]. 地学前缘,10(增刊):66–73. Deng Q D,Zhang P Z,Ran Y K,Yang X P,Min W,Chen L C. 2003. Active tectonics and earthquake activities in China[J]. Earth Science Frontiers,10(S1):66–73 (in Chinese).
丁鉴海, 卢振业, 余素荣. 2011. 地震地磁学概论[M]. 合肥: 中国科学技术大学出版社: 159–223. Ding J H, Lu Z Y, Yu S R. 2011. A Brief Treatise on Seismomagnetism[M]. Hefei: China University of Science and Technology Press: 159–223 （in Chinese）.
冯丽丽,康国发,付虹. 2012. 汶川、通海、澜沧强地震区的岩石圈磁场分布特征[J]. 云南大学学报(自然科学版),34(增刊):27–32. Feng L L,Kang G F,Fu H. 2012. Lithospheric magnetic field distribution characteristics of Wenchuan earthquake area,Tonghai earthquake area and Lancang earthquake area[J]. Journal of Yunnan University:Natural Science Edition,34(S2):27–32 (in Chinese).
顾春雷,张毅,徐如刚,王雷. 2010. 地震前后岩石圈磁场变化特征分析[J]. 地球物理学进展,25(2):472–477. doi: 10.3969/j.issn.1004-2903.2010.02.013 Gu C L,Zhang Y,Xu R G,Wang L. 2010. Analysis of the variation characteristic in the lithospheric geomagnetic field before and after earthquakes[J]. Progress in Geophysics,25(2):472–477 (in Chinese).
顾左文,张毅,姚同起,高金田,刘欣,陈斌,詹志佳,顾春雷. 2006. 九江—瑞昌MS5.7地震地磁异常的观测与分析[J]. 地震学报,28(6):611–621. doi: 10.3321/j.issn:0253-3782.2006.06.006 Gu Z W,Zhang Y,Yao T Q,Gao J T,Liu X,Chen B,Zhan Z J,Gu C L. 2006. Observation and analysis of geomagnetic abnormity associated with the MS5.7 Jiujiang-Ruichang earthquake[J]. Acta Seismologica Sinica,28(6):611–621 (in Chinese).
顾左文,陈斌,高金田,辛长江,袁洁浩,狄传芝. 2009. 应用NOC方法研究中国地区地磁时空变化[J]. 地球物理学报,52(10):2602–2612. doi: 10.3969/j.issn.0001-5733.2009.10.020 Gu Z W,Chen B,Gao J T,Xin C J,Yuan J H,Di C Z. 2009. Research of geomagnetic spatial-temporal variations in China by the NOC method[J]. Chinese Journal of Geophysics,52(10):2602–2612 (in Chinese).
康国发,高国明,白春华,王天媛,王一咪,朱腾. 2013. 喜马拉雅东构造结周边地区地壳磁异常分布特征研究[J]. 地球物理学报,56(11):3877–3886. doi: 10.6038/cjg20131129 Kang G F,Gao G M,Bai C H,Wang T Y,Wang Y M,Zhu T. 2013. Study on distribution features of crustal magnetic anomalies around eastern Himalayan syntaxis[J]. Chinese Journal of Geophysics,56(11):3877–3886 (in Chinese).
李莎,康国发. 2014. 蒙古及邻区内源磁场基本特征[J]. 云南大学学报(自然科学版),36(3):371–377. Li S,Kang G F. 2014. The basic characteristics of internal magnetic field in Mongolia and its adjacent[J]. Journal of Yunnan University:Natural Sciences Edition,36(3):371–377 (in Chinese).
倪喆,陈双贵,袁洁浩,伊炜,王粲. 2014. 芦山7.0级地震前后岩石圈磁场异常变化研究[J]. 地震研究,37(1):61–65. doi: 10.3969/j.issn.1000-0666.2014.01.009 Ni Z,Chen S G,Yuan J H,Yi W,Wang C. 2014. Research on anomalies variation of lithosphere magnetic field before and after Lushan MS7.0 earthquake[J]. Journal of Seismological Research,37(1):61–65 (in Chinese).
苏维刚,刘磊,袁伏全,赵玉红,孙玺皓. 2021. 2021年玛多MS7.4地震前玉树地震台井水温异常特征[J]. 地震学报,43(3):1–5. doi: 10.11939/jass.20210079 Su W G,Liu L,Yuan F Q,Zhao Y H,Sun X H. 2021. The anomaly characteristics of well water temperature in Yushu seismic station before the 2021 Maduo MS7.4 earthquake[J]. Acta Seismologica Sinica,43(3):1–5 (in Chinese).
文丽敏,康国发,白春华,高国明,郑安燃,安柏林. 2017. 云南地区地壳磁异常与地质构造[J]. 地球物理学报,60(9):3493–3504. doi: 10.6038/cjg20170918 Wen L M,Kang G F,Bai C H,Gao G M,Zheng A R,An B L. 2017. Crustal magnetic anomalies and geological structure in the Yunnan region[J]. Chinese Journal of Geophysics,60(9):3493–3504 (in Chinese).
熊盛青,杨海,丁燕云,李占奎. 2016. 中国陆域居里等温面深度特征[J]. 地球物理学报,59(10):3604–3617. doi: 10.6038/cjg20161008 Xiong S Q,Yang H,Ding Y Y,Li Z K. 2016. Characteristics of Chinese continent Curie point isotherm[J]. Chinese Journal of Geophysics,59(10):3604–3617 (in Chinese).
徐文耀. 2004. 地磁学[M]. 北京: 地震出版社: 1–34. Xu W Y. 2004. Geomagnetism[M]. Beijing: Seismological Press: 1–34 （in Chinese）.
徐文耀. 2009. 地球电磁现象物理学[M]. 合肥: 中国科学技术大学出版社: 18–58. Xu W Y. 2009. Physics of Electromagnetic Phenomena of the Earth[M]. Hefei: China University of Science and Technology Press: 18–58 （in Chinese）.
杨杰,李琪,袁伊人. 2021. 2013年3月3日洱源MS5.5地震前地磁转换函数异常研究[J]. 地震学报,43(2):215–226. doi: 10.11939/jass.20200047 Yang J,Li Q,Yuan Y R. 2021. Geomagnetic transform function anomaly before the MS5.5 Eryuan earthquake on March 3,2013[J]. Acta Seismologica Sinica,43(2):215–226 (in Chinese).
姚休义,冯志生. 2018. 地震磁扰动分析方法研究进展[J]. 地球物理学进展,33(2):511–520. doi: 10.6038/pg2018BB0063 Yao X Y,Feng Z S. 2018. Review on the recent development of analysis methods on magnetic disturbance associated with earthquakes[J]. Progress in Geophysics,33(2):511–520 (in Chinese).
詹艳,梁明剑,孙翔宇,黄飞鹏,赵凌强,宫悦,韩静,李陈侠,张培震,张会平. 2021. 2021年5月22日青海玛多MS7.4地震深部环境及发震构造模式[J]. 地球物理学报,64(7):2232–2252. doi: 10.6038/cjg2021O0521 Zhan Y,Liang M J,Sun X Y,Huang F P,Zhao L Q,Gong Y,Han J,Li C X,Zhang P Z,Zhang H P. 2021. Deep structure and seismogenic pattern of the 2021.5.22 Madoi (Qinghai) MS7.4 earthquake[J]. Chinese Journal of Geophysics,64(7):2232–2252 (in Chinese).
张培震,邓起东,张国民,马瑾,甘卫军,闵伟,毛凤英,王琪. 2003. 中国大陆的强震活动与活动地块[J]. 中国科学:地球科学,33(增刊):12–20. Zhang P Z,Deng Q D,Zhang G M,Ma J,Gan W J,Min W,Mao F Y,Wang Q. 2003. Active tectonic blocks and strong earthquakes in the continent of China[J]. Science China Earth Sciences,46:13–24.
Busse F H. 2011. Geomagnetic field, theory[C]// Gupta H K. （eds）. Encyclopedia of Solid Earth Geophysics. Dordrecht: Springer: 394–401.
Campbell W H. 2003. Introduction to Geomagnetic Fields[M]. 2nd ed. Cambridge: Cambridge University Press: 239–252.
Dong C,Zhang H,Jiao L G,Cheng H H,Yuen D A,Shi Y L. 2021. The non-negligible effect of viscosity diffusion on the geodynamo process[J]. J Geophys Res:Solid Earth,126(6):e2020JB021281.
Gu Z W,Zhan Z J,Gao J T,Han W,An Z C,Yao T Q,Chen B. 2006. Geomagnetic survey and geomagnetic model research in China[J]. Earth,Planet Space,58(6):741–750.
Johnston M J S,Sasai Y,Egbert G D,Mueller R J. 2006. Seismomagnetic effects from the long-awaited 28 September 2004 M6.0 Parkfield earthquake[J]. Bull Seismol Soc Am,96(4B):S206–S220. doi: 10.1785/0120050810
Kuang W J,Bloxham J. 1997. An Earth-like numerical dynamo model[J]. Nature,389(6649):371–374. doi: 10.1038/38712
Maus S,Rother M,Hemant K,Stolle C,Lühr H,Kuvshinov A,Olsen N. 2006. Earth’s lithospheric magnetic field determined to spherical harmonic degree 90 from CHAMP satellite measurements[J]. Geophys J Int,164(2):319–330. doi: 10.1111/j.1365-246X.2005.02833.x
Mörner N A. 1986. The lithospheric geomagnetic field:Origin and dynamics of long wavelength anomalies[J]. Phys Earth Planet Inter,44(4):366–372. doi: 10.1016/0031-9201(86)90065-8
Thébault E,Purucker M,Whaler K A,Langlais B,Sabaka T J. 2010. The magnetic field of the Earth’s lithosphere[J]. Space Sci Rev,155(1/4):95–127.
Wessel P,Smith W H F,Scharroo R,Luis J,Wobbe F. 2013. Generic mapping tools:Improved version released[J]. Eos,Trans Am Geophys Union,94(45):409–410.
Zhang P Z,Shen Z K,Wang M,Gan W J,Bürgmann R,Molnar P,Wang Q,Niu Z J,Sun J Z,Wu J C,Sun H R,You X Z. 2004. Continuous deformation of the Tibetan Plateau from global positioning system data[J]. Geology,32(9):809–812. doi: 10.1130/G20554.1
-
