Characteristics of the dominant azimuth anomalies of geoelectric field at Dawu station before MS7.4 Maduo，Qinghai earthquake in 2021
-
摘要: 为了深入了解2021年5月22日青海省玛多MS7.4地震前是否存在地震电信号，本文利用地电场优势方位角方法对大武地电场的原始资料进行了分析，获得了玛多地震前震中附近场地的岩体裂隙结构变化特征，并结合本次地震震中500 km范围内八个地电场台站的岩体裂隙结构变化和该台记录到的以往震例中大武台地电场优势方位角异常变化与中强地震之间的关系进行了综合分析。结果显示：大武台新旧两套地电场数据的地电场优势方位角在震前11个月出现了显著的同步偏转现象，其中大武旧台在震前两个月优势方位角再次出现大幅度上升，异常特征主要表现为优势方位角出现同步快速偏转，最大偏转达到45°—90°；处于同一次级地块的甘孜台、玛曲台与大武台出现准同步异常现象，而其它次级地块上的台站均无异常出现，表明异常响应受到区域构造的影响。再结合大武台地电场使用该方法分析的以往震例表明：大武台的地电场优势方位角异常在中强地震前具有较好的中短期指示意义。Abstract: In order to know whether there were seismic electrical signals before MS7.4 Maduo, Qinghai earthquake on 22 May 2021, this paper analyzed the original data of geoelectric field from Dawu seismic station by using the dominant azimuth method, and the variation characteristics of rockmass fracture structure before the MS7.4 Maduo earthquake were obtained. Furthermore, the rockmass frasture structure characteristics of eight geoelectric stations within 500 km of the earthquake and previous related earthquake cases are comprehensively analyzed. The results show that the geoelectric field dominant azimuths of the two observation sites at Dawu had a significantly synchronous deflection phenomenon eleven months before the earthquake, and the geoelectric field of one site increased sharply again one month before the earthquake. The abnormal characteristics of the site are mainly manifested as the rapid deflection of the jump range of the dominant azimuth, with the maximum deflection reaching 45°−90°. Additionally, the stations Garze and Maqu in the same secondary block showed quasisynchronous changes with the Dawu station, while the stations in other secondary blocks showed no anomalies, indicating that the abnormal responses are affected by regional tectonic settings. And combined with the previous earthquake case analyses, it is deduced that the dominant azimuth anomaly based on the Dawu electric field has good prediction efficiency for the short and medium term earthquake.
-
-
![]()
图 1 玛多MS7.4地震震中及附近地电场台站分布
Figure 1. Location of the epicenter of Maduo MS7.4 earthquake and distribution of the geoelectric stations
![]()
图 2 大武地震台（旧）地电场观测布极图
Figure 2. Electrode distribution of electric field （old site） of Dawu seismic station
![]()
图 3 2020年以来大武台地电场旧（a）、新（b）台的地电场优势方位角变化
Figure 3. The variation of the dominant azimuth of geoelectric field at old （a） and new （b） sites of Dawu station since 2020
![]()
图 4 2020年以来甘孜（a）、玛曲台（b）的地电场方位角异常变化
Figure 4. The variation of the dominant azimuth angle based on geoelectric field data at the seismic stations Garze （a） and Maqu （b） since 2020
表 1 玛多MS7.4地震前震中500 km内地电场优势方位角的变化特征
Table 1 Variation characteristic of the dominant azimuth based on geoelectric field before MS7.4 Maduo earthquake within 500 km
地电场台站 震中距/km 异常形态 异常出现日期
年-月-日开始观测日期
年-月-日大武（旧） 170 快速偏转，Δα≈45° 2020-05-10 2014-12-12 大武（新） 169 Δα增大至90° 2020-05-08 2020-01-01 玛曲 335 Δα增大至60° 2020-05-04 2014-03-22 甘孜 360 快速偏转，Δα≈90° 2020-05-15 2017-12-01 都兰 190 无异常 无 2014-12-01 白水河 355 无异常 无 2015-01-01 金银滩 256 无异常 无 2019-06-04 门源地电场 433 无异常 无 2020-01-01
下载: 导出CSV
表 2 大武台周围500 km范围内MS5.5地震前地电场优势方位角的变化特征
Table 2 Variation characteristic of dominant azimuth based on geoelectric field before MS5.5 earthquakes within 500 km of Dawu station
台站 发震日期
年-月-日发震地点 MS 震中距/km 异常 异常出现月份
年-月备注 大武台 2016-01-21 门源 6.4 380 Δα增大 2015-10 多台同步 2016-10-17 杂多 6.2 500 震前2个月快速偏转恢复 2016-08 附近仅一台 2017-08-08 九寨沟 7.0 360 无 无 无 2019-10-28 夏河 5.7 240 快速偏转 2019-06 多台同步 2020-04-01 石渠县 5.6 200 震前3个月快速偏转恢复 2020-01 多台同步
下载: 导出CSV
-
艾萨·伊斯马伊力,陈界宏,毛志强. 2020. 2016—2017年北天山地区两次6级地震前地电场异常[J]. 电波科学学报,35(3):430–436. Yisimayili A,Chen J H,Mao Z Q. 2020. Geoelectric anomalies before the two M6 earthquakes in northern Tianshan in 2016−2017[J]. Chinese Journal of Radio Science,35(3):430–436 (in Chinese).
安张辉,高悦,范莹莹,刘君,王建军. 2017. 地电潮汐力谐振共振波研究回顾与展望[J]. 地球物理学进展,32(1):1–7. doi: 10.6038/pg20170101 An Z H,Gao Y,Fan Y Y,Liu J,Wang J J. 2017. Review and prospect for the harmonic resonance waves of geo-electricity driven by tidal forces[J]. Progress in Geophysics,32(1):1–7 (in Chinese).
陈全,安张辉,范莹莹. 2019. 南北地震带潮汐触发地震的统计学证据[J]. 地球物理学进展,34(5):1714–1720. Chen Q,An Z H,Fan Y Y. 2019. Statistical evidence of tidal triggered earthquakes in North and South Seismic Belt[J]. Progress in Geophysics,34(5):1714–1720 (in Chinese).
范莹莹,杜学彬,Jacques Zlotnicki,谭大诚,刘君,安张辉,陈军营,郑国磊,解滔. 2010. 汶川MS8.0大震前的电磁现象[J]. 地球物理学报,53(12):2887–2898. Fan Y Y,Du X B,Jacques Z,Tan D C,Liu J,An Z H,Chen J Y,Zheng G L,Xie T. 2010. The electromagnetic phenomena before the MS8.0 Wenchuan earthquake[J]. Chinese Journal of Geophysics,53(12):2887–2898 (in Chinese).
黄清华. 2005. 地震电磁观测研究简述[J]. 国际地震动态,(11):4–7. Huang Q H. 2005. The state-of-the-art in seismic electromagnetic observation[J]. Developments in World Seismology,(11):4–7 (in Chinese).
黄清华,刘涛. 2006. 新岛台地电场的潮汐响应与地震[J]. 地球物理学报,49(6):1745–1754. Huang Q H,Liu T. 2006. Earthquakes and tide response of geoelectric potential field at the Niijima station[J]. Chinese Journal of Geophysics,49(6):1745–1754 (in Chinese).
马钦忠. 2008. 地电场多极距观测装置系统与文安MS5.1地震前首都圈地电场异常研究[J]. 地震学报,30(6):615–625. Ma Q Z. 2008. Multi-dipole observation system and study on the abnormal variation of the geoelectric field observed at Capital Network before the 2006 Wen’an,Hebei of China,MS5.1 earthquake[J]. Acta Seismologica Sinica,30(6):615–625 (in Chinese).
毛桐恩,席继楼,王燕琼,尹淑芝. 1999. 地震过程中的大地电场变化特征[J]. 地球物理学报,42(4):520–528. Mao T E,Xi J L,Wang Y Q,Yin S Z. 1999. The variation characteristics of the telluric field in the process of earthquake[J]. Chinese Journal of Geophysics,42(4):520–528 (in Chinese).
钱复业,赵玉林. 2005. 地电场短临预报方法研究[J]. 地震,25(2):33–40. doi: 10.3969/j.issn.1000-3274.2005.02.005 Qian F Y,Zhao Y L. 2005. Study on geoelectric field method for short-term and impending earthquake prediction[J]. Earthquake,25(2):33–40 (in Chinese).
谭大诚,赵家骝,席继楼,杜学彬,徐建明. 2010. 潮汐地电场特征及机理研究[J]. 地球物理学报,53(3):544–555. Tan D C,Zhao J L,Xi J L,Du X B,Xu J M. 2010. A study on feature and mechanism of the tidal geoelectrical field[J]. Chinese Journal of Geophysics,53(3):544–555 (in Chinese).
谭大诚,王兰炜,赵家骝,席继楼,刘大鹏,于华,陈军营. 2011. 潮汐地电场谐波和各向波形的影响要素[J]. 地球物理学报,54(7):1842–1853. doi: 10.3969/j.issn.0001-5733.2011.07.018 Tan D C,Wang L W,Zhao J L,Xi J L,Liu D P,Yu H,Chen J Y. 2011. Influence factors of harmonic waves and directional waveforms of tidal geoelectrical field[J]. Chinese Journal of Geophysics,54(7):1842–1853 (in Chinese).
谭大诚,赵家骝,席继楼,刘大鹏,安张辉. 2012. 青藏高原中强地震前的地电场变异及构成解析[J]. 地球物理学报,55(3):875–885. Tan D C,Zhao J L,Xi J L,Liu D P,An Z H. 2012. The variation of waveform and analysis of composition for the geoelectrical field before moderate or strong earthquakes in Qinghai-Tibetan Plateau regions[J]. Chinese Journal of Geophysics,55(3):875–885 (in Chinese).
谭大诚,席继楼,张慧,王兰炜,范莹莹,安海静. 2013. 地电场水文地质因素及裂隙水主体渗流方向逐日计算[J]. 地震学报,35(1):36–49. doi: 10.3969/j.issn.0253-3782.2013.01.005 Tan D C,Xi J L,Zhang H,Wang L W,Fan Y Y,An H J. 2013. Hydrogeologic factors of geoelectric field and diurnal computation of preferred orientation of crack water seepage[J]. Acta Seismologica Sinica,35(1):36–49 (in Chinese).
谭大诚,辛建村,王建军,范莹莹,王玮铭. 2019. 大地电场岩体裂隙模型的应用基础与震例解析[J]. 地球物理学报,62(2):558–571. Tan D C,Xin J C,Wang J J,Fan Y Y,Wang W M. 2019. Application foundation and earthquake case analysis of the telluric field rock crack model[J]. Chinese Journal of Geophysics,62(2):558–571 (in Chinese).
田山,王建国,徐学恭,董洪军,崔晓峰,马骥. 2009. 大地电场观测地震前兆异常提取技术研究[J]. 地震学报,31(4):424–431. Tian S,Wang J G,Xu X G,Dong H J,Cui X F,Ma J. 2009. Research on the technique of extracting seismic precursory anomaly from telluric electric field observation[J]. Acta Seismologica Sinica,31(4):424–431 (in Chinese).
席继楼. 2019. 地电场观测方法与观测技术研究[J]. 地震地磁观测与研究,40(2):1–20. Xi J L. 2019. A review of geoelectric field observation methods and techniques[J]. Seismological and Geomagnetic Observation and Research,40(2):1–20 (in Chinese).
辛建村,谭大诚,赵菲,张远富,李旭升. 2017. 典型干扰对岩体裂隙优势方位计算结果的影响研究[J]. 地震,37(4):112–122. Xin J C,Tan D C,Zhao F,Zhang Y F,Li X S. 2017. Calculation of preferred orientation of rock cracks influenced by typical interferences[J]. Earthquake,37(4):112–122 (in Chinese).
叶青,杜学彬,周克昌,李宁,马占虎. 2007. 大地电场变化的频谱特征[J]. 地震学报,29(4):382–390. Ye Q,Du X B,Zhou K C,Li N,Ma Z H. 2007. Spectrum characteristics of geoelectric field variation[J]. Acta Seismologica Sinica,29(4):382–390 (in Chinese).
詹艳. 2008. 青藏高原东北缘地区深部电性结构及构造涵义[D]. 北京: 中国地震局地质研究所: 60–61. Zhan Y. 2008. Deep Electric Structures Beneath the Northeastern Margin of the Tibetan Plateau and Its Tectonic Implications[D]. Beijing: Institute of Geology, China Earthquake Administration: 60–61 （in Chinese）.
张波,谭大诚,罗娜,尹小兵,吴鹤帅. 2020. 高压直流输电对大柏舍台地电场观测干扰的分析[J]. 地震,40(1):140–150. Zhang B,Tan D C,Luo N,Yin X B,Wu H S. 2020. Interference analysis of HVDC transmission to electric field observation of Dabaishe station[J]. Earthquake,40(1):140–150 (in Chinese).
Varotsos P,Alexopoulos K. 1984a. Physical properties of the variations of the electric field of the earth preceding earthquakes,I[J]. Tectonophysics,110(1/2):73–98.
-
