唐山地震时北京及邻区砂土液化深度的探讨

A DISCUSSION ON THE DEPTHS OF LIQUEFIED SANDY SOILS IN BEIJING AND ADJACENT REGIONS DURING THE 1976 TANGSHAN EARTHQUAKE

  • 摘要: 砂土液化深度历来是工程界颇为关心的问题.以往研究砂土液化深度多靠间接或宏观的方法, 因而取得的结果彼此间差别很大, 本文提出一种建立在喷砂同地下砂层直接对比基础上的矿物学方法.唐山地震之后, 作者等收集北京通县的西集、王庄(以上为 Ⅷ 度烈度区), 河北香河县的骡子王、渠口、县城大气所(以上为 Ⅶ 度区)等五个钻孔剖面上的砂样及地表喷砂、并进行矿物与颗粒成分的研究.结果表明, 西集喷砂同地下12.26米砂层类似;王庄喷砂同地下11.02米砂层类似;骡子王喷砂同地下12.3米砂层类似;大气所喷砂同地下9.2米砂层类似;渠口喷砂同地下11.28米砂层类似.据此可以认为, 唐山地震时北京通县与河北香河等地的 Ⅶ 和 Ⅷ 度烈度区的最大液化深度不超过12.30米, 变化在9.2——12.30米之间, Ⅶ 度区有可能更浅些.



    Abstract: The determination of the depth of liquefied sandy soil is an all concerned problem in earthquake engineering. Previous studies of the depth of liquefied sandy soil have been done with indirect or macroscopic methods, giving quite varied results. In this paper, we propose a mineralogical method for study of liquefaction, basing on the direct correlation of ejected sands with subsurface sand layers.After the 1976 Tangshan Earthquake, the present authors collected samples of sands in five drill holes and of ejected sands on the surface in the areas of Xiji and Wangzhuan of the Tongxian County with seismic intensity Ⅷ, and areas of Luosi-wang, Qukou and Xianghe, Hebei Province with seismic intensity Ⅶ. The results of investigation by mineralogical and granulometric analysis indicate that the ejected sands are similar to the sands from a layer at depth of 12.26 m in the area of Xiji, to the sands from depth of 11.02 m in Wangzhuang area, to the sands from depth of 12.3 m in Luoziwang area and to the sands from depth of 9.2 m in the area of Xianghe and the sands from depth 11.28 in Qukou area.According to these data we can conclude that the maximum depth of liquefaction of sandy soils does not exceed 12.30 m in areas with seismic intensity of Ⅶ and Ⅷ for the Tongxian and Xianghe Counties during the Tangshan Earthquake of 1976 and varies in the range from 9.2 to 12.30 m and is probably shallower in areas with inten-sitv Ⅶ.



/
