You X Z，Lin B H，Li J，Guo Y，Yu W H，Li S L. 2023. Evaluation of early warning capability of Fujian Province seismic network. Acta Seismologica Sinica，45（1）：126−141. DOI: 10.11939/jass.20210173
Citation: You X Z，Lin B H，Li J，Guo Y，Yu W H，Li S L. 2023. Evaluation of early warning capability of Fujian Province seismic network. Acta Seismologica Sinica，45（1）：126−141. DOI: 10.11939/jass.20210173
shu

Evaluation of early warning capability of Fujian Province seismic network

  • 1.

    Fujian Earthquake Agency，Fuzhou 350003，China

  • 2.

    Xiamen Institute of Marine Seismology，China Earthquake Administration，Fujian Xiamen 361021，China

More Information
  • Received Date: November 14, 2021
  • Revised Date: March 10, 2022
  • Available Online: December 18, 2022
  • Published Date: January 16, 2023
    Graphical Abstract
    • Abstract
  • Since the common root-mean-square method and noise power spectrum method cannot eliminate the noise interference recorded by different types of sensors, we use the maximum probability peak displacement as the background noise evaluation index to calculate the noise level more accurate. Based on the reliable noise data, referring to the magnitude maximum distance monitoring capability method and considering the timeliness of earthquake early warning （EEW）, an EEW minimum magnitude evaluation method is proposed. This new method can systematically evaluate the minimum magnitude of EEW and the warning time of independent three types of sensor networks and their fusion networks in Fujian. The results show that the minimum magnitude of EEW based on the fusion networks of the seismometer and the strong seismometer is higher than that of the single seismometer network, and obviously lower than that of the strong seismometer network. For fusion networks of strong seismometer and intensity meter, the minimum magnitude of EEW is similar to that of single intensity meter network. After integrating three types of networks, the minimum magnitude of EEW in 95% regions is about ML3.2. Because the density of intensity meter network is higher than the seismometer and strong seismometer network, the warning time is the shortest. Compared with the single seismometer network or single strong seismometer network, the warning time of EEW has been significantly reduced by three types sensor fusion networks, and the warning time in 95% regions is 4−6 seconds after an earthquake occurred as it is estimated. This study provides a reference to optimize the distribution of networks and increase the monitoring capacity of key regions in Fujian province.
    • FullText(HTML)
    • References (21)
  • 白琳娟. 2017. 区域及高速铁路地震预警系统的效能分析[D]. 哈尔滨: 中国地震局工程力学研究所: 1−79.
    Bai L J. 2017. The Performance Evaluation for Earthquake Early Warning Systems for Region and High-Speed Railway[D]. Harbin: Institute of Engineering Mechanics, China Earthquake Administration:1−79 （in Chinese）.
    蒋长胜,房立华,韩立波,王未来,郭路杰. 2015. 利用PMC方法评估地震台阵的地震检测能力:以西昌流动地震台阵为例[J]. 地球物理学报,58(3):832–843. doi: 10.6038/cjg20150313
    Jiang C S,Fang L H,Han L B,Wang W L,Guo L J. 2015. Assessment of earthquake detection capability for the seismic array:A case study of the Xichang seismic array[J]. Chinese Journal of Geophysics,58(3):832–843 (in Chinese).
    林彬华,金星,廖诗荣,李军,黄玲珠,朱耿青. 2015. 地震噪声异常实时监测[J]. 中国地震,31(2):281–289. doi: 10.3969/j.issn.1001-4683.2015.02.012
    Lin B H,Jin X,Liao S R,Li J,Huang L Z,Zhu G Q. 2015. Real-time monitoring of abnormal seismic noise[J]. Earthquake Research in China,31(2):281–289 (in Chinese).
    刘栋. 2018. 福建省测震台网监测能力研究[D]. 哈尔滨: 中国地震局工程力学研究所:1−63.
    Liu D. 2018. Research on Monitoring Capacity of Seismological Network in Fujian Province[D]. Harbin: Institute of Engineering Mechanics, China Earthquake Administration: 1−63. （in Chinese）.
    刘洋君,杨毅,王燕,康承旭. 2016. 浙江测震台网地震监测能力分析[J]. 地震地磁观测与研究,37(4):57–61.
    Liu Y J,Yang Y,Wang Y,Kang C X. 2016. Analysis of seismic monitoring capacity of Zhejiang seismic network[J]. Seismological and Geomagnetic Observation and Research,37(4):57–61 (in Chinese).
    王俊,蔡舒梅,崔庆谷. 2007. 云南区域数字地震台网的监测能力与限幅问题[J]. 地震地磁观测与研究,28(1):84–89. doi: 10.3969/j.issn.1003-3246.2007.01.014
    Wang J,Cai S M,Cui Q G. 2007. The research for earthquake monitoring and clipping level of Yunnan seismic network[J]. Seismological and Geomagnetic Observation and Research,28(1):84–89 (in Chinese).
    王亚文,蒋长胜,刘芳,毕金孟. 2017. 中国地震台网监测能力评估和台站检测能力评分(20081−63.2015年)[J]. 地球物理学报,60(7):2767–2778. doi: 10.6038/cjg20170722
    Wang Y W,Jiang C S,Liu F,Bi J M. 2017. Assessment of earthquake monitoring capability and score of seismic station detection capability in China seismic network (2008-2015)[J]. Chinese Journal of Geophysics,60(7):2767–2778 (in Chinese).
    袁丽文,郑斯华,周峥嵘. 2009. 福建地区地震活动特征及区域应力场研究[J]. 东北地震研究,25(3):37–44.
    Yuan L W,Zheng S H,Zhou Z R. 2009. Research on seismicity characteristics and regional stress field in Fujian area[J]. Seismological Research of Northeast China,25(3):37–44 (in Chinese).
    张红才,金星,李军,韦永祥,马强. 2012. 地震预警震级计算方法研究综述[J]. 地球物理学进展,27(2):464–474. doi: 10.6038/j.issn.1004-2903.2012.02.009
    Zhang H C,Jin X,Li J,Wei Y X,Ma Q. 2012. Review on magnitude estimation methods applied to earthquake early warning systems[J]. Progress in Geophysics,27(2):464–474 (in Chinese).
    中华人民共和国国家质量监督检验检疫总局, 中国国家标准化管理委员会. 2017. GB 17740−2017 地震震级的规定[S]. 北京: 中国标准出版社: 1−15.
    General Administration of Quality Supervision, Inspection and Quarantine of the People’s Republic of China, Standardization Administration of the People’s Republic of China. 2017. GB 17740−2017 General Ruler for Earthquake Magnitude[S]. Beijing: China Standards Press:1−15 （in Chinese）.
    Schorlemmer D,Woessner J. 2008. Probability of detecting an earthquake[J]. Bull Seismol Soc Am,98(5):2103–2117. doi: 10.1785/0120070105
